Jet Pendant
Model#: UJE-95XXX, UJE-951XX Ratings: IP65 CE IK08 ETL
A range of round or square shaped pendant exterior or interior downlight luminaires utilizing a combination of high output LEDs and precision optics that can provide Type II, III & IV distributions as well as Type V distributions with narrow, medium, wide and very wide beams. The Type II, III & IV distribution options should be used to provide wide spacing to mounting height ratios with excellent uniformity. This luminaire has specialized optics that have been designed by Ligman, in conjunction with internationally recognized optic designers to provide excellent light control, beam distribution and intensities by focusing each optic around the small LEDs to provide perfect focus and distribution. This luminaire can be provided with a variety of anti-glare and light control attachments.
This pendant range is available with 2 different suspension options.
- Aircraft Cable: Field adjustable to suit design criteria and will always hang vertical, even if the fixture is bumped or moved.
- Rigid Stem: Supplied with 1/2" rigid stem and swivel mount attachment that complies with seismic requirements, as well as sloped ceilings with angles up to 80°
Other Fixtures in the Jet Design Family:
Spec Sheets and Downloads for Jet Pendant
Specification Sheets
Jet 43 Cylindrical Pendant Downlight 4”
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Beam
|
Dimmable 1-10V
|
UJE-95081 |
14
|
1618 lm
|
27K,30K,35K,40K
|
20°-24°-36°-71°
|
•
|
Jet 45 Cylindrical Pendant Downlight 6.3”
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Beam
|
Dimmable 1-10V
|
UJE-95111 |
39
|
4094 lm
|
27K,30K,35K,40K
|
13°-20°-40°-61°
|
•
|
Jet 44 Square Pendant Downlight 4”
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Beam
|
Dimmable 1-10V
|
UJE-95091 |
14
|
1618 lm
|
27K,30K,35K,40K
|
20°-24°-36°-71°
|
•
|
Jet 46 Square Pendant Downlight 6.3”
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Beam
|
Dimmable 1-10V
|
UJE-95121 |
39
|
4094 lm
|
27K,30K,35K,40K
|
13°-20°-40°-61°
|
•
|
Photometric and Downloads
Product Information |
Jet square photometric IES |
Jet square CAD Files (2D / RFA / 3DS) |
IFC - BIM |
Dialux Files .uld |
