Syndy Symmetrical Post Top
Model#: USY-20XXX Ratings: IP65 CE IK07 ETL
Suitable for wet locations A modern post top luminaire with excellent downward symmetrical light distribution and visual appeal. The precision optical system gives very low glare rating, while reducing light pollution. Designed for lighting entrances, footpaths and car parks. Low copper content die-cast aluminium housing with high corrosion resistance. Stainless steel screws. Durable silicone rubber gasket and clear toughened glass. Housing is treated with a chemical chromatized protection before powder coating, ensuring high corrosion resistance. High performance COB LED light engine. White painted aluminium reflector on the top of luminaire.
Other Fixtures in the Syndy Design Family:
Spec Sheets and Downloads for Syndy Symmetrical Post Top
Specification Sheets
Syndy Symmetrical
|
|
Model No. |
Watts
|
Lumens
|
Kelvin
|
Dimmable 1-10V
|
USY-20931-40w |
40
|
2328 lm
|
27K,30K,35K,40K
|
•
|
USY-20931-55w |
55
|
3139 lm
|
27K,30K,35K,40K
|
•
|
*Contact factory for LED 90w options available
Accessories
Aluminium arm pole clamp | ||
A20176 |
Aluminium single arm post top | ||
A20276 |
Aluminium double arm post top | ||
A20376 |
Photometric and Downloads
Product Information |
Syndy photometric IES |
Syndy CAD Files (2D / RFA / 3DS) |
IFC - BIM |
Dialux Files .uld |
